Digital Rockwell Hardness Tester Model 900-415
Product Details
Shipping charges will include Customs Brokerage, Duty, and Insurance
Features
- Load Cell driven system provides precise control of test force application
- Automatic conversions to HB, HV, Superficial Rockwell Scales
- Touch Screen selectable system
- Upper/Lower Limit Settings
This digital Rockwell hardness tester with fully automated load/unload procedures affords highly sensitive and accurate readings. Micro computer controlled Touch Screen with USB output to flash drive. Utilizing the guidelines of ASTM E-18, the 900-415 digital Rockwell hardness tester offers programmable scale conversions, dwell times, statistical capabilities and test counter. Capable of testing in all of the regular Rockwell hardness scales.
Direct Loading Method With Load-Cell Instead Of Dead Weight System. High Speed Test Cycle and Extremely Accurate Loading Control
- Automatic conversions to HB, HV, Superficial Rockwell Scales
- Touch Screen selectable system
- Upper/Lower Limit Settings
- Test resolution: 0.01HR Rockwell unit;
- Operation temperature:50° – 95°F (10ᵒC～35ᵒC)
- Ambient environment: clean, no vibration, no strong magnetic field, and no corrosive medium;
- Power supply:single phase, AC, 110-220 with manual change, 50～60Hz, 4A;
Specifications:Rockwell Hardness Tester
| Minor Load | 10 Kgf |
|---|---|
| Major Load | 60 Kgf, 100 Kgf, 150 KGF |
| Test Force Application | Load Cell Closed Loop |
| Test Force Control | Motorized |
| Results Display | Hi Def LCD Digital Readout |
| Resolution | 0.1HR |
| Vertical Capacity | 8.0” |
| Throat Depth | 7.8” |
| Height | 22” |
| Width | 8” |
| Depth | 31” |
| Weight | 175 lbs |
Included Accessories
- C-scale Diamond Indenter
- 1/16” Ball Indenter
- 3- HRC test Blocks
- 1- HRB Test Block
- Test Table 5.87” (150mm)
- Flat Anvil 2.5” (63mm)
- Std. V- Anvil
- Dust Cover
- Accessory Case
